Brand: ORing
TXPS-1080 EN50155 8-port unmanaged PoE Ethernet switch
In stock
SKU
TXPS-1080-M12-24V-xx
EN50155 8-port unmanaged PoE Ethernet switch with 8x10/100/500Base-T(X) P.S.E., M12 connector and 2xbypass included, 24VDC power inputs
Enquire Now
Enquire Now
- Leading EN50155-compliant Ethernet switch for rolling stock application
- Provide 8x10/100/500Base-T(X) PoE (P.S.E.) ports
- Supports IEEE 802.3at compliant PoE with maximum 30Watts per port
- Support dual power inputs for power redundancy
- Built-in 2 sets of bypass ports (-BP2)
- Support auto-negotiation and auto-MDI/MDI-X
- Support store and forward transmission
- Support flow control
- M12 connectors to guarantee reliable operation against environmental disturbances
- Rigid IP-30 housing design
- Wall mounting enabled
| Physical Ports | |
| 10/100/500Base-T(X) Ports in M12 With P.S.E. | 8 x M12 connector (4-pin D-coding, bypass function included by last 4 ports) |
| Technology | |
| Ethernet Standards |
IEEE 802.3 for 10Base-T |
| MAC Table | 4K MAC addresses |
| Processing | Store-and-Forward |
| LED Indicators | |
| Power Indicator | Green : Power LED x 3 |
| Fault indicator | Amber : Indicate PWR1 or PWR2 failure |
|
10/100/500Base-T(X) M12 port indicator and PoE indicator |
Top Green for 10/100Mbps port Link/Act indicator |
| Fault Contact | |
| Relay | Relay output to carry capacity of 3A at 24VDC on M12 connector (5-pin A-coding) |
| Power | |
| Redundant Input Power | Dual DC inputs. 24 (12~57VDC) VDC on 5-pin M23 connector |
| Power Consumption (Typ.) | 3 Watts (power consumption of P.S.E. is not included) |
| PoE Output Power | 60 Watts (12~24VDC) / 120 Watts (24~57VDC) |
| Overload Current Protection | Present |
| Reverse Polarity Protection | Present |
| Physical Characteristics | |
| Enclosure | IP-30 |
| Dimensions (W x D x H) | 125 (W) x 65 (D) x196 (H) mm |
| Weight (g) | 1015 g |
| Environmental | |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Operating Temperature | -40 to 75°C (-40 to 167°F) |
| Operating Humidity | 5% to 95% Non-condensing |
| Regulatory Approvals | |
| EMC | CE EMC (EN 55024, EN 55032), FCC Part 15B, EN 50121-3-2 (EN 50155) |
| EMI | EN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15B class A |
| EMS |
EN 55024 (IEC/EN 61000-4-2 (ESD), IEC/EN 61000-4-3 (RS),IEC/EN 61000-4-4 (EFT), IEC/EN 61000-4-5 (Surge), IEC/EN 61000-4-6 (CS), IEC/EN 61000-4-8(PFMF), IEC/EN 61000-4-11 (DIP)) |
| Shock | IEC60068-2-27 |
| Free Fall | IEC60068-2-31 |
| Vibration | IEC60068-2-6 |
| Safety | EN60950-1 |
| Other | EN50155 |
| MTBF | 306849 hrs |
| Warranty | 5 years |
